NCERT Solutions for Class 12 Physics Chapter 4 Moving Charges and Magnetism
4.1 A circular coil of wire consisting of 100 turns, each of radius 8.0 cm carries a current of 0.40 A. What is the magnitude of the magnetic field B at the centre of the coil?
Solution :
Given , n = 100 , r = 8 cm = 0.08m , I = 0.4 A
Magnitude of the magnetic field at the centre of the coil is given by the relation,
$$\left | B \right | = \frac{\mu_{0} }{4\pi }.\frac{2\pi nI}{r}$$
where $\mu_{0} =4\pi \times10^{-7}TmA^{-1}$
$$B = \frac{4\pi \times 10^{-7}}{4\pi }.\frac{2\pi \times 100 \times 0.4}{0.08}$$
$$B = 10^{-7}. \frac{2\pi \times 10^{2} \times 4 \times 10^{-1} }{8 \times 10^{-2}}$$
$$B = \frac{2\pi \times 4}{8}.\frac{10^{-7} \times 10^{^{2}} \times 10^{-1}}{10^{-2}}$$
$$B = \pi \times 10^{-7+2-1+2}$$
$$B = 3.14 \times 10^{-4}T$$
4.2 A long straight wire carries a current of 35 A. What is the magnitude of the field B at a point 20 cm from the wire?
Solution :
Given I = 35 A , r = 20 cm = .2m
Magnitude of the magnetic field at this point is given as
$$B = \frac{\mu_{0} }{4\pi }.\frac{2I}{r}$$
where $\mu_{0} =4\pi \times10^{-7}TmA^{-1}$$
$$B = \frac{4\pi \times 10^{-7} \times 2 \times 35}{4\pi \times 0.2}$$
$$B = \frac{2 \times 35 \times 10^{-7}}{2 \times 10^{-1}}$$
$$B = 35 \times 10^{-7} \times 10^{1}$$
$$B = 35 \times 10^{-6}$$
$$B = 3.5 \times 10^{1} \times 10^{-6}$$
$$B = 3.5 \times 10^{-5}T$$
4.3 A long straight wire in the horizontal plane carries a current of 50 A in north to south direction. Give the magnitude and direction of B at a point 2.5 m east of the wire.
Solution :
Given I = 50 A , r = 2.5 m
Magnitude of the magnetic field at this point is given as
$$B = \frac{\mu_{0} }{4\pi }.\frac{2I}{r}$$
where $\mu_{0} =4\pi \times10^{-7}TmA^{-1}$
$$B = \frac{4\pi \times 10^{-7} \times 2 \times 50}{4\pi \times 2.5}$$
$$B = \frac{2 \times 50}{2.5} \times 10^{-7}$$
$$B = \frac{100}{2.5}\times 10^{-7}$$
$$B = \frac{100}{25 \times 10^{-1}} \times 10^{-7}$$
$$B = 4\times 10^{-7} \times 10^{1}$$
$$B = 4 \times 10^{-6}T$$
4.4 A horizontal overhead power line carries a current of 90 A in east to west direction. What is the magnitude and direction of the magnetic field due to the current 1.5 m below the line?
Solution :
Given I = 90 A , r = 1.5 m
Magnitude of the magnetic field at this point is given as
$$B = \frac{\mu_{0} }{4\pi }.\frac{2I}{r}$$
where $\mu_{0} =4\pi \times10^{-7}TmA^{-1}$$
$$B = \frac{4\pi \times 10^{-7} \times 2 \times 90}{4\pi \times 1.5}$$
$$B = \frac{10^{-7}\times 180}{1.5}$$
$$B = \frac{180 \times10^{-7} }{1.5}$$
$$B = \frac{180 \times10^{-7} }{15 \times 10^{-1}}$$
$$B = 12 \times10^{-7} \times 10^{1}$$
$$B = 12 \times 10^{-6}$$
$$B = 1.2 \times10^{1} \times 10^{-6}$$
$$B = 1.2 \times 10^{1-6}$$
$$B = 1.2 \times 10^{-5}T$$
The current is flowing from East to West. The point is below the power line. Hence , according to maxwell's right hand thumb rule, the direction of the magnetic field is towards the South.
4.5 What is the magnitude of magnetic force per unit length on a wire carrying a current of 8 A and making an angle of $30^{0}$ with the direction of a uniform magnetic field of 0.15 T?
Solution :
Given , I = 8A , B = 0.15 T , $\theta = 30^{0}$ ,
Magnetic force per unit length on the wire is given as :
$$f = Blsin\theta$$
$$f = 0.15 \times 8 \times 1 \times sin30^{0}$$
$$f = 0.6Nm^{-1}$$
Hence , the magnetic force per unit length on the wire is $0.6 Nm^{-1}$
4.6 A 3.0 cm wire carrying a current of 10 A is placed inside a solenoid perpendicular to its axis. The magnetic field inside the solenoid is given to be 0.27 T. What is the magnetic force on the wire?
Solution :
Length of the wire , l = 3 cm = 0.03 m
Current flowing in the wire , I = 10 A
Magnetic field , B = 0.27 T
Angle between the current and magnetic field , $\theta = 90^{0}$
Magnetic force exerted on the wire is given as :
$$F = B.l.i.sin \theta$$
$$F = 0.27 \times 10 \times 0.03 \times sin 90^{0}$$
$$F = 8.1 \times 10^{-2} N$$
Hence , the magnetic force on the wire is $F = 8.1 \times 10^{-2} N.$ The direction of the force can be obtained from Fleming's left hand rule.
4.7 Two long and parallel straight wires A and B carrying currents of 8.0 A and 5.0 A in the same direction are separated by a distance of 4.0 cm. Estimate the force on a 10 cm section of wire A.
Solution :
$$I_{A} = 8.0 A$$
$$I_{B} = 5.0 A$$
$$r = 4.0 cm = 0.04 m$$
$$l = 10 cm = 0.1 m$$
Force exerted on length l due to the magnetic field is given as :
$$F = \frac{\mu_{0} }{4\pi }.\frac{2I_{1}I_{2}l}{r}$$
$$F = 10^{-7} \times \frac{2\times 8 \times 5 \times 0.1}{0.04}$$
$$F = 2 \times 10^{-5}N$$
The magnitude of force is $2\times 10^{-5} N$ . this is an attractive force normal to A towards B because the direction of the currents in the wires is the same.
4.8 A closely wound solenoid 80 cm long has 5 layers of windings of 400 turns each. The diameter of the solenoid is 1.8 cm. If the current carried is 8.0 A, estimate the magnitude of B inside the solenoid near its centre.
Solution :
l = 80 cm = 0.8 m ,
There are five layers of windings of 400 turns each on the solenoid`
so , Total number of turns on the solenoid , $N = 5 \times 400 = 2000$
Diameter of the solenoid , D = 1.8 cm = 0.018 m
Current carried by the solenoid , I = 8.0 A
Magnitude of the magnetic field inside the solenoid near its centre is given by the relation,
$$B = \frac{\mu_{0}NI}{l}$$
$$B = \frac{4\pi \times 10^{-7} \times 2000 \times 8}{0.8}$$
$$B = 8\pi \times 10^{-3}$$
$$B = 2.512 \times 10^{-2}T$$
4.9 A square coil of side 10 cm consists of 20 turns and carries a current of 12 A. The coil is suspended vertically and the normal to the plane of the coil makes an angle of $30^{o}$ with the direction of a uniform horizontal magnetic field of magnitude 0.80 T. What is the magnitude of torque experienced by the coil?
Solution :
i = 12 A
L = 10 cm = 0.1 m
Number of turns on the coil , n = 20
Angle made by the plane of the coil with magnetic field, 0=30°
Strength of magnetic field. B = 0.80 T Magnitude of the magnetic torque experienced by the coil in the magnetic field is given by the relation.
$$\tau = n.B.i.A.sin\theta$$
$$A = L \times L = 0.1 \times 0.1 = 0.01 m^{2}$$
$$\tau = 20 \times 0.8 \times 12 \times 0.01 \times sin 30^{0}$$
$$\tau = 0.96 N$$
Hence, the magnitude of the torque experienced by the coil is 0.96 N m
4.10 Two moving coil meters , $M_{1}$ and $M_{2}$ have the following particulars :
$$R_{1} = 10 \Omega , N_{1} = 30$$
$$A_{1} = 3.6 \times 10^{-3} m^{2} , B_{1} = 0.25 T$$
$$R_{2} = 14 \Omega , N_{2} = 42$$
$$A_{2} = 1.8 \times 10^{-3} m^{2} , B_{2} = 0.50T$$
(The spring constants are identical for the meters).
Determine the ratio of (a) Current Sensitivity and (b) Voltage sensitivity of $M_{2}$ and $M_{1}$.
Solution :
For moving coil meter $M_{1}$ :
Resistance, $R_{1}=10\Omega$
Number of turns , $N_{1} = 30$
Area of cross-section, $A_{1}= 3.6 \times 10^{-3} m^{2}$
Magnetic field strength, $B_{1}=0.25T$
Spring constant $K_{1} = K$
For moving coil meter $M_{2}$ :
Resistance, $R_{2} = 14 \Omega$
Number of turns, $N_{2} = 42$
Area of cross-section, $A_{2} = 1.8 \times 10^{-3} m^{2}$
Magnetic field strength, $B_{2} = 0.50T$
Spring constant $K_{2} = K$
(a) Current sensitivity of $M_{1}$ is given as:
$$I_{S1} = \frac{N_{1}B_{1}A_{1}}{K_{1}}$$
Current sensitivity of $M_{2}$ is given as:
$$I_{S2} = \frac{N_{2}B_{2}A_{2}}{K_{2}}$$
$$\frac{I_{s2}}{I_{s1}} = \frac{\frac{N_{2}B_{2}A_{2}}{K_{2}}}{\frac{N_{1}B_{1}A_{1}}{K_{1}}}$$
$$\frac{I_{s2}}{I_{s1}}=\frac{N_{2}B_{2}A_{2}K_{1}}{K_{2}N_{1}B_{1}A_{1}}$$
$$\frac{I_{s2}}{I_{s1}} = \frac{42\times 0.5 \times 1.8 \times 10^{-3} \times K}{K \times 30 \times 0.25 \times 3.6 \times 10^{-3}}$$
$$\frac{I_{s2}}{I_{s1}} = \frac{14}{10}$$
$$\frac{I_{s2}}{I_{s1}} = \frac{7}{5}$$
hence, the ratio of current sensitivity of $M_{2}$ of $M_{1}$ is 1.4
4.11 In a chamber, a uniform magnetic field of 6.5 G ($1 G = 10^{–4} T$) is maintained. An electron is shot into the field with a speed of $4.8 \times 10^{6}m s^{–1}$ normal to the field. Explain why the path of the electron is a circle. Determine the radius of the circular orbit. ($e = 1.6 \times 10^{–19} C$, $m= 9.1 \times 10^{–31} kg$)
Solution:
Magnetic field strength, $B = 6.5 G = 6.5 \times 10^{–4}T $
Speed of the electron, $v = 4.8 \times 10^{6}$ m/s
Charge on the electron, $e = 1.6 \times 10^{–19} C$
Mass of the electron, $m= 9.1 \times 10^{–31} kg$
Angle between the shot electron and magnetic field, θ = 90° Magnetic force exerted on the electron in the magnetic field is given as:
$$F_{m} = qvB sinθ$$
$$F_{m} = evB sinθ$$
This force provides centripetal force to the moving electron. Hence, the electron starts moving in a circular path of radius r. Hence, centripetal force exerted on the electron,
$$F_{c} =\frac{mv^{2}}{r}$$
In equilibrium, the centripetal force exerted on the electron is equal to the magnetic force i.e.,
$$F_{c} = F_{m}$$
$$\frac{mv^{2}}{r} = evBsin\theta$$
$$r = \frac{mv}{eBsin\theta}$$
$$r = \frac{9.1 \times 10^{-31} \times 4.8 \times 10^{6}}{1.6 \times 10^{-19} \times 6.5 \times 10^{-4}}$$
$$r = 4.2 \times 10^{-2}m$$
$$r = 4.2 cm$$
4.12 In Exercise 4.11 obtain the frequency of revolution of the electron in its circular orbit. Does the answer depend on the speed of the electron? Explain.
Solution :
Magnetic field strength, $B = 6.5 \times 10^{−4} T$
Charge of the electron, $e = 1.6 \times 10^{−19} C$
Mass of the electron, $m_{e} = 9.1 \times 10^{−31} kg$
Velocity of the electron, $v = 4.8 \times 10^{6} m/s$
Radius of the orbit, r = 4.2 cm = 0.042 m
Frequency of revolution of the electron = f
Angular frequency of the electron = ω = 2πf
Velocity of the electron is related to the angular frequency as:
v = rω.
In the circular orbit, the magnetic force on the electron is balanced by the centripetal force. Hence, we can write:
$$evB = \frac{mv^{2}}{r}$$
$$eB = \frac{mv}{r}$$
$$eB = \frac{m(r\omega)}{r}$$
$$eB = m \omega$$
$$eB = m \times 2\pi f$$
$$Frequency, f = \frac{eB}{2\pi m}$$
This expression for frequency is independent of the speed of the electron. On substituting the known values in this expression, we get the frequency as:
$$f = \frac{(1.6 \times 10^{-19}) \times (6.5 \times 10^{-4})}{2 \pi \times 9.1 \times 10^{-31}}$$
$$f = 18.18 \times 10^{6} Hz$$
$$f = 18MHz$$
Hence, the frequency of the electron is around 18 MHz and is independent of the speed of the electron.
4.13 (a) A circular coil of 30 turns and radius 8.0 cm carrying a current of 6.0 A is suspended vertically in a uniform horizontal magnetic field of magnitude 1.0 T. The field lines make an angle of 60° with the normal of the coil. Calculate the magnitude of the counter torque that must be applied to prevent the coil from turning.
(b) Would your answer change, if the circular coil in (a) were replaced by a planar coil of some irregular shape that encloses the same area? (All other particulars are also unaltered.)
Solution:
I = 6.0 A ,
n = 30 ,
B = 1 T ,
$\alpha= 60^{0}$ ,
r = 8 cm = $8.0 \times 10^{-2}m$
Area of the coil ,
$$A = \pi r^{2}$$
$$A= \pi \times (8.0 \times 10^{-2})^{2}$$
$$A= 2.01 \times 10^{-2}m^{2}$$
(a) Deflecting torque ,
$$\tau = nIABsin \alpha$$
$$\tau= 30 \times 6 \times 2.01 \times 10^{-2} \times 1 \times sin 60^{0}$$
$$\tau= 3.133 Nm$$
So , Counter torque = Deflecting torque =3.133 Nm
(b) No , It is because torque on the planet loop is independent of its shape provided the area (A) of the loop remains the same.
